Glossary
Glossary of common OpenCue terms
This page defines common terminology for OpenCue.
Allocation
An allocation is a group for organizing render hosts by associating them with a facility and a tag. Render hosts exist within an allocation and inherit their facility and a tag from the allocation.
Cores
The processing units that make up a proc.
Cue
A nickname for the entire queuing system, which also prefixes the names of OpenCue rendering tools, such as CueGUI and Cuebot.
CueAdmin
Command-line administrative tools for OpenCue system management, providing scripting capabilities for automation, bulk operations, and system maintenance tasks. Written in Python and provides a thin layer over the OpenCue Python API, PyCue.
Cuebot
The central management server that performs critical OpenCue tasks including managing job submissions, distributing work to render nodes, and responding to API requests from client tools. Typically runs on a server and can be deployed in clusters for high availability.
CueGUI
The desktop graphical user interface divided into two main workspaces: Cuetopia (artist-focused job monitoring) and CueCommander (administrator-focused system management). Provides comprehensive tools for job monitoring, frame inspection, host management, and system administration.
Cueman
A specialized tool for managing and monitoring OpenCue deployments, providing additional administrative capabilities and system oversight functions.
CueSubmit
A graphical user interface for configuring and launching rendering jobs. Typically runs as a plug-in within 3D software like Maya, Blender, or Nuke, allowing artists to submit jobs directly from their creative applications.
CueWeb
A web-based interface that brings CueGUI’s core functionality to the browser. Offers job management, frame monitoring, real-time updates, and collaborative features accessible from anywhere on the network without requiring client installation.
Dependent job
A job which won’t run until the frames of another job are completed.
Facility
Facilities can be used to label and separate farm resources. This is generally done based on physical locations to help guide jobs to hosts in that location. Both jobs and allocations belong to a facility. Jobs submitted to a facility will only run on allocations within that same facility.
Frames
An individual command that’s contained in a layer.
Hard dependency
A frame-to-frame dependency, where only the corresponding frames need to finish.
Host
A machine that is running an instance of rqd. This machine will split up into procs to execute work.
Job
A job is a collection of layers, which is sent as a script to the queue to be processed on remote cores.
Layers
The sub-jobs in an outline script job. Each layer contains a frame range and a command to execute.
Outline script
A powerful tool for submitting jobs to the queue. You can define an outline script to batch multiple job submissions into a single job, setting up dependencies and / or running in parallel. Outline scripts can submit almost any type of job to the cue, including Maya, Katana, or even shell commands.
Proc
A proc is a slot on a render host that has been carved out and isolated to execute a frame.
OpenCue REST Gateway
A production-ready HTTP service that translates REST API calls to gRPC communication with Cuebot. Enables web applications, scripts, and third-party tools to interact with OpenCue services through standard HTTP endpoints.
PyCue
The Python API library that provides programmatic access to OpenCue functionality. Used by client applications and custom scripts to interact with Cuebot’s gRPC interface. OpenCue client-side Python tools, such as CueGUI and CueAdmin, all use PyCue for communicating with your OpenCue deployment.
PyOutline
A Python library for creating job specifications and render job descriptions. Provides the framework for defining complex rendering workflows and job dependencies. It provides a Python interface to the job specification XML, allowing you to construct complex jobs with Python code instead of working directly with XML. CueSubmit uses PyOutline to construct its job submissions.
Queue
A queue is a render farm that processes a large number of render jobs according to defined priorities.
RQD (Python)
The render queue daemon that runs on all rendering hosts. RQD registers hosts with Cuebot, receives work instructions, monitors worker processes, and reports results back to the central server. This is the original Python implementation.
Rust RQD
A high-performance implementation of RQD written in Rust, providing the same functionality as Python RQD with improved performance and resource efficiency.
Service
A service is a collection of resource requirements and tags that are associated with a layer. The service contains minimum and maximum thread requirements, minimum memory and gpu requirements, whether the jobs are threadable or not, and a list of tags. These attributes are inherited by layers submitted to that service by default. Services can be used to setup different requirements for different software jobs. For instance, a Maya render may need 6GB of memory vs a Nuke render may only need 2GB.
Show
A show is a group of related work to be done. Jobs submitted to OpenCue exist within a show. Subscriptions list the available allocations to a given show.
Soft dependency
When all the frames of the first job need to finish before the second job can begin.
Subscription
A Subscription is an object that associates multiple allocations with a show. This drives what render hosts can do work for a show.
Tag
A string that can be assigned to a render host and a layer. Frames contained in a layer with a tag will only render on a host that also shares that tag.
Relationships
This diagram depicts the connections between the primary objects within OpenCue As you can see the majority of connections follow a one-to-many type of relationship. For example, a job can be connected to many layers. With the understanding that a frame can only run on a proc that shares the same tag and facility, you can walk this diagram to determine where these settings are coming from in your jobs.
